Technical specifications for AMPAC USA commercial reverse osmosis systems — complete system specs, membrane counts, pump ratings, dimensions, and operating parameters for the full product line. Use this page to match a system to your daily water requirement and feed water conditions, or to pull specs for a capital equipment proposal.
Quick navigation: APRO300 (300 GPD) · AP1500 (1,500 GPD) · AP2200 (2,200 GPD) · APRO6000 (6,000 GPD) · How to Choose
APRO300 — Commercial RO System, 300 GPD / 1,135 LPD
Entry-level commercial RO for light-duty applications: small restaurants, dental offices, craft beverage operations, and laboratory Type III water. Designed for municipal and well feed water up to 1,500 ppm TDS. Wall-mount or counter-top installation. Ships pre-assembled.
| Parameter | Specification |
|---|---|
| SKU / Model | APRO300 |
| Rated capacity | 300 GPD / 1,135 LPD |
| TDS rejection | 98% average (new membrane) |
| Membrane | 1 × TFC 4″ × 14″ high-flow element |
| Pre-filtration (included) | 20″ 5-micron sediment pre-filter; 20″ KDF-GAC-polyphosphate pre-filter; 20″ CTO+2 carbon block pre-filter |
| Pump | Aquatech booster pump, 110V/220V, 50/60 Hz |
| Feed pressure required | 40–80 PSI |
| Power supply | 110V/60Hz or 220V/50Hz |
| Max feed TDS | 1,500 ppm (municipal); 2,500 ppm (brackish config) |
| Max feed temperature | 113°F / 45°C |
| Feed pH range | 3–11 |
| Max chlorine | <0.1 ppm (carbon pre-filter included) |
| Connections | John Guest quick-disconnect push-fit fittings |
| Gauges | Liquid-filled pre-filter pressure gauge; liquid-filled booster pump pressure gauge |
| Safety controls | High-pressure cut-off switch; high-pressure needle valve |
| Optional storage | 14-gallon pressurized storage tank |
| Components | FDA/NSF certified, US-sourced |
| Origin | Manufactured in Pomona / Montclair, CA, USA |
| Warranty | 2-year parts |
Typical applications: Small restaurant ice and beverage water, dental office sterilizer water, laboratory Type III rinse water, craft beverage pre-treatment, light commercial car wash spot-rinse.
View APRO300 product page · Request a quote
AP1500 — Commercial RO System, 1,500 GPD / 5,670 LPD
Mid-range commercial RO for food service facilities, hotels, car washes, and commercial laundries with 1,200–1,800 GPD daily purified water demand. Handles feed water TDS up to 2,500 ppm. Stainless steel frame, continuous duty up to 20 hours/day. Ships pre-assembled and factory-tested.
| Parameter | Specification |
|---|---|
| SKU / Model | AP1500 |
| Rated capacity | 1,500 GPD / 5,670 LPD |
| Flow rate | 3.9 L/min continuous |
| TDS rejection | 96–99% (FILMTEC™ membranes) |
| Membranes | 3 × FILMTEC™ 4″ × 40″ (DuPont) in FRP pressure vessels |
| Pre-filtration (included) | 5-micron sediment pre-filter + activated carbon block |
| Feed pressure required | 40–80 PSI |
| Recovery rate | 50–75% (adjustable) |
| Power supply | 110V/60Hz standard; 220V available |
| Max feed TDS | 2,500 ppm |
| Max feed temperature | 113°F / 45°C |
| Feed pH range | 3–11 |
| Max chlorine | <0.1 ppm |
| Connections | 3/8″ push-fit quick-connect |
| Frame | Stainless steel, corrosion-resistant |
| Safety controls | Automatic shut-off valve; low-pressure cut-off switch |
| Certification | NSF-certified components |
| Origin | Manufactured in Pomona / Montclair, CA, USA |
| Warranty | 2-year parts; 1-year membranes |
Typical applications: Full-service restaurant (ice, beverage, steam), hotel laundry pre-treatment, express car wash spot-free rinse, commercial greenhouse irrigation, small dialysis or dental clinic.
Sizing note: At 55°F feed water (cold well water), derated output is approximately 1,050 GPD. Add storage tank sized for 12–16 hours of demand to decouple production from peak use.
View AP1500 product page · Request a quote
AP2200 — Commercial RO System, 2,200 GPD / 8,300 LPD
High-output commercial RO for large restaurants, hotel laundry, light manufacturing, and commercial greenhouse operations requiring 2,000–3,000 GPD of purified water. Dual-membrane configuration supports multiple simultaneous point-of-use applications. Microprocessor control panel with TDS monitoring and alarms. NSF/ANSI 58 certified.
| Parameter | Specification |
|---|---|
| SKU / Model | AP2200 |
| Rated capacity | 2,200 GPD / 8,300 LPD |
| Flow rate | 5.8 L/min continuous |
| TDS rejection | 96–99% (FILMTEC™ membranes) |
| Membranes | 4 × FILMTEC™ 4″ × 40″ (DuPont) |
| Pre-filtration (included) | 5-micron sediment pre-filter + carbon block |
| Feed pressure required | 50–80 PSI |
| Recovery rate | 50–75% (adjustable) |
| Power supply | 110V/60Hz or 220V/60Hz |
| Max feed TDS | 3,000 ppm |
| Max feed temperature | 113°F / 45°C |
| Feed pH range | 3–11 |
| Max chlorine | <0.1 ppm |
| Feed connection | 3/4″ male NPT |
| Drain connection | 1/2″ OD tube |
| Frame | Welded stainless steel skid, color-coded plumbing |
| Controls | Microprocessor panel; alarms for low pressure, high TDS, tank-full |
| Certification | NSF/ANSI 58 |
| Permeate TDS (typical) | 50–300 ppm (dependent on feed TDS and membrane age) |
| Storage compatibility | Supports 230-gallon atmospheric storage tank (sold separately) |
| Origin | Manufactured in Pomona / Montclair, CA, USA |
| Warranty | 2-year parts and labor; 1-year membranes |
Typical applications: Full-service hotel (kitchen + ice + beverage), regional brewery pre-treatment, full-service car wash spot-free rinse, commercial cannabis cultivation, light food processing (beverage, dairy, baking).
View AP2200 product page · Request a quote
APRO6000 — Commercial RO System, 6,000 GPD / 22,750 LPD
Heavy-duty commercial and light industrial RO for large food processing operations, industrial laundry, commercial car wash facilities, and high-volume water treatment applications. Four-membrane array on powder-coated welded aluminum skid. Fully configurable with optional PLC automation, antiscalant dosing, softener pre-stage, and UV sterilizer. Available in manual or fully automated configurations.
| Parameter | Specification |
|---|---|
| SKU / Model | APRO6000 |
| Rated capacity | 6,000 GPD / 22,750 LPD |
| Flow rate | 4.2 GPM / 15.8 L/min continuous |
| TDS rejection | 99% typical (new membrane) |
| Membranes | 4 × TFC 4″ × 40″ elements in 4″ × 40″ pressure vessels (stainless steel or FRP) |
| Pre-filtration (included) | Spin-down screen filter with manual flush valve; 4″ × 20″ Big Blue 20-micron sediment pre-filter; 4″ × 20″ Big Blue 5-micron sediment pre-filter; silica quartz pre-filter with auto-backwash valve |
| Pump | Goulds multi-stage jet pump with safeguards, 2 HP / 1,725 RPM (SS option available) |
| Operating pressure | 170–225 PSI |
| Recovery rate | 33–75% (municipal); configurable |
| Power supply | 110V or 220V, 50/60 Hz, 1-phase or 3-phase |
| Max feed TDS (municipal) | 2,500 ppm / 15 grains |
| Max feed TDS (brackish) | 10,000 ppm / 25 grains |
| Max feed temperature | 113°F / 45°C |
| Feed pH range | 2–11 |
| Max chlorine | <0.1 ppm |
| Connections | 1″ quick tubing connectors |
| Gauges | 4 × stainless steel glycerin-filled pressure gauges (pre-filter, post-filter, booster pump positions) |
| Flowmeters | Permeate and concentrate inline flowmeters |
| Valves | Inlet solenoid with bypass; stainless steel system pressure control; stainless steel recycle pressure valve |
| Safety controls | Low-pressure cut-off pressure switch; tank-full cutout |
| Frame | Powder-coated welded aluminum with aluminum diamond plate base |
| Dimensions | 22″ W × 22″ D × 57″ H |
| Weight | 180 lbs / 82 kg |
| Origin | Manufactured in North America (Pomona / Montclair, CA, USA) |
| Lead time | 2–3 weeks from receipt of purchase order |
APRO6000 Optional Configurations
The APRO6000 is available with the following factory-installed options:
- PLC automation package (UL/CE approved): smart relay, delayed high-pressure pump start, inlet solenoid control, low/high feed pressure switch controls, supply and delivery pump controls, storage tank full pump on/off, auto-flush cycle, pre-treat lockout, TDS/conductivity monitor, temperature monitor, hour meter
- Ion exchange water softener with auto-backwash valve
- Multimedia KDF-catalytic carbon-polyphosphate pre-filter with auto-backwash valve
- Anti-scalant dosing system (hard water / high-silica applications)
- Chlorine dosing system (iron/manganese present conditions)
- Smart-on-demand delivery pump to point of use, 2 HP
- 4″ × 10″ Big Blue carbon post-filter, 5 micron
- UV sterilizer
- Smart-on-demand supply pump to increase feed pressure, 1 HP
- Ozone generator disinfection on circulation loop
Typical applications: Industrial laundry, commercial car wash (full-service, multi-bay), regional food and beverage manufacturer, large hotel or resort, commercial cannabis cultivation facility, pharmaceutical water pre-treatment first stage.
View APRO6000 product page · Request a quote
Choosing the Right System Size
| Daily Demand | Recommended Model | Membranes | Typical Use Case |
|---|---|---|---|
| Up to 400 GPD | APRO300 | 1 × 4″ × 14″ | Small restaurant, dental office, lab Type III, light commercial |
| 800–1,500 GPD | AP1500 | 3 × 4040 FILMTEC™ | Full-service restaurant, hotel (kitchen), express car wash, small hotel |
| 1,500–3,000 GPD | AP2200 | 4 × 4040 FILMTEC™ | Large restaurant, hotel laundry, light manufacturing, regional brewery |
| 4,000–7,000 GPD | APRO6000 | 4 × 4040 TFC | Industrial laundry, food processing, full-service car wash, large hotel |
| 7,000–10,000+ GPD | APRO8000 / AP10K-LX | Multi-vessel array | Industrial manufacturing, municipal pre-treatment, bottled water |
Temperature derating reminder: Rated capacities are at 77°F (25°C) standard test conditions. Cold feed water reduces output approximately 3% per °F below 77°F. Size for your minimum winter feed water temperature, not summer averages. Use the RO flow rate calculator to derate your target model.
Not sure which system fits? Provide your daily water demand (GPD), feed water source, TDS or a water test, and your minimum winter feed water temperature. Contact AMPAC USA — we’ll specify the right system, pre-treatment, and storage configuration. Same-day response, one business day quote. All AMPAC USA commercial systems ship factory-tested from Montclair, CA with a 2-year parts warranty and domestic replacement parts stocked for same-day shipment.
