Pre-Treatment Solutions For A Better Reverse Osmosis Experience

Maintaining reverse osmosis systems is the key to ensuring longer lifespan of the system. Regular maintenance helps in a lot of ways but additionally, one needs to make sure the system does not get the unnecessary load of impurities. When the supply water contains hard metals or suspended particles in huge amounts, the membrane, the core of the RO process takes a beating thus decreasing its lifespan. Here we discuss some pre-treatment solutions in the form of filters one can apply to prevent membrane harm.

At the height of its popularity now, reverse osmosis remains the most effective methods for water filtration. Having said that, along with searching for alternative methods, steps are being taken to make sure it remains one of the best solutions yet for filtration systems. The process has a few drawbacks including energy consumption, rejected water and for large-scale industries, cost of operation. Reverse osmosis is the core system used in seawater desalination plants in almost the entire world. The process dominates the traditional method of water filtration, namely distillation. One particular area where reverse osmosis faces challenges are in membrane fouling.

Membrane fouling is when chemicals, microorganisms, and other substances either form a layer over the membrane requiring it to consume lots of energy without any output or degrade the membrane material. Membrane anti-fouling techniques are being worked upon so that the cost of maintaining such membranes is less. In any case, maintenance of membrane for industries like desalination is very high. On an average, a desalination plant has more than 40,000 membranes. Maintaining all those big membranes can be a huge task, which is why the water that passes through it is now pre-treated to get rid of all the elements that degrade the material. This elongates the life of the membrane.

On the list of many pretreatment solutions, given below are some of the best in eliminating fouling, scaling and chemical attack:

1. Multimedia filtration (MMF):
This technique has three major layers. One is of anthracite coal, other is of sand and garnet and the final layer contains a well-supporting layer of gravel. The large particles are trapped above near anthracite coal that floats and the smaller particles run deep down in the gravel filters. A well operated ideal MMF will filter particulates of the size 15-20 microns. In case of coagulants used for combining small particles together, it can eliminate sizes up to 5-10 microns.

2. Microfiltration (MF):
This process is helpful in removing the majority of dust particles and bacteria. It has a pore size of 0.1-10 micrometer. It has the capacity of reducing fouling material from the membrane. The idea is to pass water through the membrane itself which will contain hollow fibers. The water passed would be impure and full of sediments. The water on the other side of the fiber will have no such impurities and will be passed through the membrane for further filtration.

3. Antiscalants:
Are solutions added to the feed water before it is filtered. It reduces the potential of the feed water to scale the membrane away. These and scale inhibitors work by interfering in the process of scale and crystal formation. The amount of such a solution to be used completely depends on the make of theReverse Osmosis system and more importantly the chemistry of the feed water.

4. Water softeners:
These can be added to the water that would replace scale-forming ions with non-scale forming ions. However, it is important to keep another filter layer like a 5-micron cartridge to be sure of underdrains in case the water softener does not work.

Sodium bisulfate:
This is very useful in removing residual chlorine from the water which gives odor and in high amounts can damage the membranes. When added in proper amounts to the feed water it is capable of removing all of the chlorine.

5. Granular Activated carbon (GAC):
This method is effective in removing both residual chemicals and organic material. The GAC media is made up of either carbon, wood or nutshells. The activated carbon is responsible for reacting chemically with chlorine and chloramines to reduce them to chlorine ions that are not oxidizing. And therefore the effect is not seen on membranes. The microorganisms, however, are collected at the bottom of the bed because there is nothing left from the carbon to be reactive towards organic materials. This is why a layer of bacteria forms and GAC might be required to be replaced again and again. This might not be the best solution for pretreatment of feed water in RO.

Removing the chemicals is as important as the pure water itself. Scalants and degraders put a hefty sum of the bill on our desks for membrane repairs and especially if you are running a business. For large scale RO, specialized experts decide which solution will be the best for reducing scaling. For residential RO, it is suggested to get a local expert who will profile the water supply carefully before installing any such system. Preferably, get an expert from the company of the system you purchased as they have more knowledge on the make and how would certain solutions react to the equipment.
